Frame & Fork
Frame: Roadmachine Gen 3 Advanced Carbon
Frame Technology: Tuned Compliance Concept Endurance
Cable Routing: ICS Technology Stealth Cable Routing
Dropout: Full Mount UDH
Rear Axle: 12×142mm Thru-Axle
Brake Mount: Flat Mount Disc
Fender Mounts: Yes
Integrated Downtube Storage: Yes
Fork
Fork: Roadmachine Gen 3 Advanced Carbon
Technology: Tuned Compliance Concept Endurance
Cable Routing: Internal
Fender Mounts: Yes
Brake Mount: Flat Mount Disc
Front Axle: 12×100mm Thru-Axle
Fork Offset: 50mm for sizes 47-51 / 45mm for sizes 54-61
Headset
Headset: Integrated
Drivetrain
Shifters/Levers: Shimano 105 Di2 R7170
Front Derailleur: Shimano 105 Di2 R7150
Rear Derailleur: Shimano 105 Di2 R7150
Crankset: Shimano 105 R7100
Chainrings: 50/34T
Cassette: Shimano HG710, 12-Speed, 11-36T
Chain: Shimano M6100, 12-Speed
Bottom Bracket: Shimano BB-RS500-PB PressFit
Brakes
Brake Calipers: Shimano 105 R7170 Hydraulic Disc
Rotors: Shimano CL700
Rotor Size: 160mm
Wheels & Tires
Front Wheel: PRD23, 23mm
Rear Wheel: PRD23, 23mm
Tires: Vittoria Rubino V
Tire Size: 700×32
Tire Type: Tube Type
Cockpit
Stem: BMC RSM 01, Integrated Cockpit System Technology
Handlebar: BMC HB D4 03, 0, 12, Alloy 6061
Handlebar Geometry: Endurance Geometry
Reach: 70mm
Drop: 125mm
Flare: 12°
Stem Angle: -8°
Bar Tape: BMC Tacky 3mm
Seat & Accessories
Seatpost: Roadmachine Carbon D-Shaped Seatpost
Seatpost Offset: 0mm for sizes 47-51 / 15mm for sizes 54-61
Seatpost: D-Fender Compatible
Saddle: Selle Italia Model X Greentech, FeC Alloy Rail, 145mm
Pedals: Not Included
Accessories: Integrated Rear Light 25, Storage Pouch
Tire Clearance & Weight Limit
Maximum Frameset Tire Clearance: Up to 40mm measured
Clearance with Supplied Front Derailleur: Limited to 34mm measured
Maximum System Weight: 242 lbs, including rider and gear
