Frameset
Frame: Teammachine SLR Gen 5, Advanced Carbon
Frame Features: Aerocore Design, ICS Technology Stealth Cable Routing, Full Mount UDH, TCC Race Compliance Level
Brake Mount: Flat Mount Disc
Rear Axle: 12×142mm Thru-Axle
Fork: Teammachine SLR Gen 5 Advanced Carbon
Fork Features: ICS Technology Stealth Cable Routing, TCC Race Compliance Level, Stealth Dropout Design
Front Axle: 12×100mm Thru-Axle
Fork Offset: 48mm for sizes 47-51 / 43mm for sizes 54-61
Cockpit
Stem: BMC RSM 01, Integrated Cockpit System Technology
Handlebar: BMC HB D4 03, 0, 6, Alloy 6061
Handlebar Geometry: 135mm drop, 70mm reach, 6° flare
Grips: BMC Tacky 3mm
Seat & Seatpost
Seatpost: Teammachine SLR 01 Gen 5 Advanced Carbon Aero Shaped Seatpost
Offset: 0mm for sizes 47-51 / 10mm for sizes 54-61
Saddle: Selle Italia Model X Greentech, FeC Alloy Rail, 145mm
Drivetrain
Shifters: Shimano 105 Di2 ST-R7170, 2×12
Front Derailleur: Shimano 105 Di2 FD-R7150
Rear Derailleur: Shimano 105 Di2 RD-R7150
Crankset: Shimano 105 FC-R7100, 52/36T
Cassette: Shimano CS-HG710, 11-36T, 12-speed
Chain: Shimano CN-M6100
Bottom Bracket: Shimano BB-RS500-PB Press-Fit
Brakes
Levers/Calipers: Shimano 105 BR-R7170
Rotors: Shimano SM-RT64 Centerlock
Rotor Size: 160mm Front / 160mm Rear
Wheels & Tires
Rims: PRD23, 23mm
Front Hub: Shimano HB-TC500-12, Center Lock, 28H
Rear Hub: Shimano FH-TC500-HL, Center Lock, 28H
Tires: Continental Grand Prix
Tire Size: 28mm
Rim Type: Non-Tubeless Rims
Tire Type: Tube Type / Tubeless Clincher Tyre
Weight & Clearance
Bike Weight: 8.6kg
Weight Reference: Size 54, without pedals, as pictured with all accessories
System Weight Limit: 110kg
Maximum Tire Clearance: 32mm measured tire
